Cnc Vtl Heavy Duty Metal Lathe Machine 3 Axis Universal Cnc Machine
Cnc Vtl Heavy Duty Metal Lathe Machine 3 Axis Universal Cnc Machine
Cnc Vtl Heavy Duty Metal Lathe Machine 3 Axis Universal Cnc Machine
Cnc Vtl Heavy Duty Metal Lathe Machine 3 Axis Universal Cnc Machine
Cnc Vtl Heavy Duty Metal Lathe Machine 3 Axis Universal Cnc Machine
Cnc Vtl Heavy Duty Metal Lathe Machine 3 Axis Universal Cnc Machine

Cnc Vtl Heavy Duty Metal Lathe Machine 3 Axis Universal Cnc Machine

Product Details

Place of Origin: Henan, China

Brand Name: BAISHUN MACHINERY

Certification: CE，ISO

Model Number: CK5225

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $66,000.00/sets 1-4 sets

Packaging Details: 1. Outside we will pack the product with plasitic to prevent wet.
2. Outside of the cnc vertical lathe machine will be packed by strong wooden pallet.

Delivery Time: 45 Working days

Supply Ability: 20 Set/Sets per Month

Get Best Price

Product Details

Product Description
Highlight:

3 Axis Universal Cnc Machine

,

Metal Lathe Machine

,

China Cnc Vtl Machine

Max. Length Of Workpiece (mm):
2500
No. Of Spindles:
Double
Machining Capacity:
Heavy Duty
Control:
CNC/Manual
Max. Weight Of Work piece:
20TON
Spindle Motor Power(kW):
55
Worktable Diameter:
2250
Rapid Traverse Of Rail Head:
4000 Mm/min
Positioning Accuracy (mm):
±0.005
Repeatability (X/Y/Z) (mm):
±0.003
Max. Length Of Workpiece (mm):
2500
No. Of Spindles:
Double
Machining Capacity:
Heavy Duty
Control:
CNC/Manual
Max. Weight Of Work piece:
20TON
Spindle Motor Power(kW):
55
Worktable Diameter:
2250
Rapid Traverse Of Rail Head:
4000 Mm/min
Positioning Accuracy (mm):
±0.005
Repeatability (X/Y/Z) (mm):
±0.003
Cnc Vtl Heavy Duty Metal Lathe Machine 3 Axis Universal Cnc Machine

High Efficiency China Cnc Vtl Heavy Duty Metal Lathe Machine 3 Axis Universal Cnc Machine



Cnc Vtl Heavy Duty Metal Lathe Machine 3 Axis Universal Cnc Machine 0



The double column vertical lathe is a cutting-edge piece of equipment that combines mechanical, electrical, and hydraulic components. It incorporates modern design principles and manufacturing techniques, leveraging CAD optimization and state-of-the-art components from both domestic and international sources.



CNC double column vertical lathe, for my company introduces the advanced technology at home and abroad, and the design was optimized by using CAD software, implement precision of the latest national standards and safety standards, configuration of advanced and reliable mechanical and electrical components, structure performance is outstanding, strong rigidity, machine tool can meet the strong cutting, worktable can carry large tonnage load, good stability, high efficiency, safe and reliable.



Machine parameter

Specifications Unit CK5225 CK5231 CK5240Q CK5240
Max.turning diameter mm 2500 3150 4000 4000
Max. height of work piece mm 1600/2000/2500 1600/2000/2500 1600/2000/2500 1600/2000/2500
Max. weight of work piece T 10/20 10/20 10/20 32
Worktable diameter mm 2250 2830 2830/3150 3200/3600
Range of table speeds r/min 2-63 2-63 2-63 2-63
Steps   16 16 16 16
Max torque of work table KN.m 63 63 63 100
Rapid traverse of rail head mm/min 4000 4000 4000 4000
Ram vertical travel of right railhead Kn 35 35 35 40
Ram vertical travel of left railhead kn 30 30 30 30
Range cutting force of right railhead mm/min 1-50 1-50 1-50 1-50
Range cutting force of right railhead mm/min 0.1-1000 0.1-1000 0.1-1000 0.1-1000
Travel of arm mm 1000 1000 1000 1250
Section of arm mm 255×200 255×200 255×200 240×240
Swivel of left and right railhead ° ±30° ±30° ±30° ±30°
Section of tool mm 40×50 40×50 40×50 50×50
Power of main motor Kw 55 55 55 75
Overall dimensions cm 569×470×480/520 605×440×493/533 690×510×480/520 690×510×480/520



Product photos
Cnc Vtl Heavy Duty Metal Lathe Machine 3 Axis Universal Cnc Machine 1
Packaging & Shipping

Payment terms

We usually use T/T, L/C

T/T:T/T 30% in advance, the balance be paid after inspection before the delivery

Before delivery, we will send you the pictures of finished machines and welcome you to come to our factory for inspection

Way of packing

FCL&LCL export standard in 20/40feet container

FCL:Sea-worthy package,machine are fixed in container and the spare parts are packed in wooden boxes

Shipping

MSK/MSC/APL/EMC/PIL and so on

Warranty

12 months under normal use except for wearing parts



Our Services

1. 24 Hours after sales service by E-mail or Phone.

2. 100% response rate.

3. Engineers available to service overseas.

4. OEM service is available

5. Warranty: 12 months, beyond the warranty period, all spare parts offered to you with factory price.



Contact

We are a direct-sale lathe machine manufacturer, not a trading company,
which means we can offer you the best prices.

Welcome get in touch with us:)
Tel:+86 18003851898
