Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine
Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine
Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine
Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine
Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine
Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine
Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine

Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine

Product Details

Place of Origin: China

Brand Name: Baishun

Certification: ISO

Model Number: BK5040

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 Set

Price: Negotiation

Packaging Details: Export standard wooden case package

Delivery Time: 20 working days

Payment Terms: T/T, L/C, Western Union

Supply Ability: 100Set/Sets per Month

Get Best Price

Product Details

Product Description
Highlight:

Automatic Keyway Slotter

,

Metal Keyway Slotter

Name:
Steel Slotting Making Machine
Model:
BK5040
Automatic:
CNC Type
Max.length Of Ram:
400mm
Functioin:
Metal Slotting
Controller:
PLC
Voltage:
380v/50hz Or As Customer Required
Warranty:
1 Year
Power (kW):
4
Weight (KG):
4200 KG
Name:
Steel Slotting Making Machine
Model:
BK5040
Automatic:
CNC Type
Max.length Of Ram:
400mm
Functioin:
Metal Slotting
Controller:
PLC
Voltage:
380v/50hz Or As Customer Required
Warranty:
1 Year
Power (kW):
4
Weight (KG):
4200 KG
Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine

Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine

This CNC Slot machines are used for interpolation plane, forming surface and Keyway Etc. And can insert the inclination in the 10° Mold and other within the scope of etc. work matter,Enterprise suitable for single or small batch production.

Metal slotting machine tools are used to process groove in workpiece. During processing, the workpiece on the worktable performs longitudinal, lateral or rotational movement, and the inserting tool reciprocates up and down to slot the workpiece. A linear motion machine tool that uses the vertical reciprocating motion of the slotting tool to slot the keyway and the hole. The slotting machine, like the planer, also uses a single-edged tool (slotting tool) to cut the workpiece, but the planer is a horizontal layout, and the slotting machine is a vertical layout. Slotting machines have high productivity and accuracy. They are mostly used to process internal keyways or spline holes in single or small batch production. They can also process flat, square or polygonal holes, etc.



The main performance characteristics:
1.The working table of the machine tool is provided with three different directions of feed (longitudinal, horizontal and rotary),
therefore work object go through once clamping, Several surfaces in the machine tool machining
2.Hydraulic transmission mechanism with sliding pillow reciprocating motion and hydraulic feed device for working table.
3.The sliding pillow has the same speed in every stroke, and the movement speed of the ram and the working table can be adjusted
continuously.
4.Hydraulic control table have ram commutation oil for oil reversing mechanism, In addition to hydraulic and manual feed outer,
Even there single motor drive vertical, horizontal and rotary fast moving.
5.Use hydraulic feed the slotting machine, Is when the work is over turning back instantaneous feed, Therefore be better than
mechanical slotting machine used drum wheel feed.


Product main technical parameters:

Item Unit BK5018 BK5030 BK5032 BK5040
Max. length of ram mm 180 300 320 400
Ram adjustment stroke mm 80 300 315 315
Number of ram movements n/min 30/120 30~150 20~80 20~80
Working desk size mm 600*320 550*405 800*610 800*610
X direction motor torque N.M 6 6 7.7 7.7
Z direction motor torque N.M 6 6 7.7 7.7
Main motor power kw 3.7 3.7 4 4
Machine weight kg 2000 2800 3700 4200
Package dimension mm 2200*2100*2300 2300*2200*2300 2800*2400*2500 2800*2400*2500





Machine picture:

Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine 0

Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine 1
Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine 2
Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine 3

Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine 4


For more detail specification please contact:
Automatic Keyway Slotter Metal Materials BK5040 Steel Slotting Making Machine 5
